Hawk-Woods RP-M90

Hawk-Woods RP-M90 – 26V 90Wh Mini Reel-Power Battery

The Hawk-Woods RP-M90 is a compact 26V 90Wh lithium-ion battery from the Mini Reel-Power series, designed for powering high-voltage cameras such as ARRI and lighting applications. With only a third of the weight of a standard Reel-Power battery, it offers longer runtimes without additional weight or bulk. Utilizing low resistance cell technology, the battery delivers high discharge currents and improved cycle life. The built-in Total Battery Protection safeguards against over-discharge, over-voltage, short-circuit, and overheating. This battery is flight-safe, as it falls within the 100Wh-160Wh limit.

Main Features

• Capacity: 90Wh (3.6Ah)
• Nominal voltage: 26V
• Maximum current draw: 6A
• V-Mount (Reel-Power) connection
• Integrated fuel gauge
• Compatible with hot-swap via RPM-HS1A
• Protections: over-discharge, over-voltage, short-circuit, thermal protection

Specifications

• Dimensions: 9.9 × 7.1 × 6.6 cm
• Weight: 490 g

Included

• 1x Hawk-Woods RP-M90 battery
